Ref :

https://github.com/gaurav157243/aws-projects/blob/main/DBOnEC2/README.MD

✅ Setting up ec2 instance :

• Login to aws console
• Create a free ec2 Instance
• SSH inside the ec2 instance (use putty/teminus for accessing in local)

Now once you are inside linux shell , install the build essentials :

Fist update the instance :
//sudo dnf update

and then install

// nodejs and npm
sudo yum -y nodejs

//install git
sudo yum -y git

// install postgres
- postgres

Inbound rules in AWS should look something like this :

Setting up elastic ip

<aside> 💡

If you don’t setup elastic IP, everytime you restart your EC2 instance , a new public ip will be generated , hence your application will break

</aside>

Associate an Elastic IP ( Optional )

• Navigate to "Elastic IPs" in the left sidebar.
• Click "Allocate Elastic IP address."
• Keep all settings default and click "Allocate."
• Select the Elastic IP, then choose "Associate Elastic IP address" from the Actions menu.
• Check "Allow this Elastic IP address to be reassociated."
• Click "Associate."

✅  Setting up Postgres Backend on EC2 instance

Install postgres on ec2 instance :

//update
sudo dnf update -y. or sudo yum update -y

// Install
sudo dnf install -y postgresql15.x86_64 postgresql15-server

//Initiate db
sudo postgresql-setup --initdb

//start
sudo systemctl start postgresql

//stop
sudo systemctl stop postgresql

// run even after ec2 closed
sudo systemctl enable postgresql

//check status
sudo systemctl status postgresql

//active
active : sudo systemctl active postgresql

Basic psql commands :

// Login inside postgres
sudo -i -u postgres or **su -u postgres**

//Open psql shell
**psl**

//list all database
postgres= \\l. or \\list

//access single database
**\\c databaas_name**

//go inside table
**\\dt

//read hidden file
ls -a

//read file
cat filename**

//close psql shel
\\q

✅  Clone your repository

git clone <reponame>
npm install

npm run build

//applocartion should run at port 3000

Test : http://<publicip>:3000

✅  Install pm2 to keep the application running :

1. Install PM2 globally:

   sudo npm install -g pm2


2. Start your Next.js app in production:

   npm run build   # only needed the first time or after code changes
   pm2 start npm --name "nextjs-app" -- start


3. Save the PM2 process list so it starts on reboot:

   pm2 save
   pm2 startup


4. Check status:

   pm2 list



5. Delete pm2 process :

pm2 stop <id or name>

✅  Install & Configure Nginx

What is nginx ?

<aside> 💡

• Nginx (pronounced Engine-X) is a high-performance web server.
• It can also work as a reverse proxy, load balancer, and HTTP/HTTPS server. </aside>

Why do we need it ?

<aside> 💡

• Serve traffic on standard ports →
  • Instead of visiting http://ip:3000, Nginx listens on port 80 (HTTP) and 443 (HTTPS).
  • It forwards requests to your Node.js app (e.g., running on port 3000).
• Enable HTTPS (SSL/TLS) →
  • Nginx makes it easy to add free SSL certificates (via Certbot).
  • So your site can run securely on https://yourdomain.com.
• Stability & Performance →
  • Handles thousands of connections efficiently.
  • Protects your Node.js app from crashing under heavy traffic.
• Reverse Proxy →
  • Hides your backend (Node.js on port 3000).
  • Clients always hit Nginx, and Nginx forwards requests internally. </aside>

Nginx will act as a reverse proxy → so instead of hitting http://EC2_IP:3000, you’ll just use http://EC2_IP.

• Step 1: Install Nginx

  On Amazon Linux:

  sudo amazon-linux-extras install nginx1 -y


  Then start it:

  sudo systemctl start nginx
  sudo systemctl enable nginx


  Check status:

  sudo systemctl status nginx


  Open browser → http://<EC2_PUBLIC_IP> → you should see Welcome to Nginx.

• Step 2: Configure Reverse Proxy

  By default, Amazon Linux doesn’t use /etc/nginx/sites-available. Instead it has a main config file:

  /etc/nginx/nginx.conf


  You can add your app config inside /etc/nginx/conf.d/nextjs.conf (recommended).

  sudo nano /etc/nginx/conf.d/nextjs.conf


  Add this:

  server {
      listen 80;

      server_name <your-ip or domain>;

      location / {
          proxy_pass <http://localhost:3000>;
          proxy_http_version 1.1;
          proxy_set_header Upgrade $http_upgrade;
          proxy_set_header Connection 'upgrade';
          proxy_set_header Host $host;
          proxy_cache_bypass $http_upgrade;
      }
  }



  Save & exit (CTRL+O, CTRL+X).

  ---

• Step 3: Restart Nginx

  sudo nginx -t   # test config
  sudo systemctl restart nginx


  Now your app will be available at:

  http://<EC2_PUBLIC_IP>


  and you don’t need to add :3000.

  ❓ Why no need to add 3000 port at the end ?

  <aside> 💡

  → Nginx listens on the default HTTP port 80 (and optionally HTTPS on port 443).

  → You tell Nginx to forward (proxy) requests from port 80 → 3000.

  </aside>

  👉 Nginx receives the request on port 80

  👉 Nginx forwards it to your Next.js app on port 3000

  👉 User never sees port 3000 in the browser.

  ---

✅ At this point:

• PM2 keeps your app running forever (even if EC2 restarts).
• Nginx routes traffic from port 80 to your Next.js app.

If you want to kill pm2 instance :

nginx stop <id/name>
nginx delete <id/name>

• Doubts

  Q1 : Why no need to add port at the end after installing nginx ?

  <aside> 💡

  → Nginx listens on the default HTTP port 80 (and optionally HTTPS on port 443).

  → You tell Nginx to forward (proxy) requests from port 80 → 3000.

  👉 Nginx receives the request on port 80

  👉 Nginx forwards it to your Next.js app on port 3000

  👉 User never sees port 3000 in the browser.

  </aside>

  Q2 : Port 80 and port 443 in nginx ?

  <aside> 💡

  • Port 80 → HTTP (unsecured)

    • It’s the default port for plain http:// traffic.
    • Example: when you type http://example.com, your browser actually connects to example.com:80 by default.
    • That’s why you don’t need to type :80 explicitly.

  • Port 443 → HTTPS (secured with SSL/TLS)

    • It’s the default port for encrypted https:// traffic.
    • Example: when you type https://example.com, your browser connects to example.com:443 automatically.
    • This port requires an SSL/TLS certificate (self-signed or issued by Let’s Encrypt/other CAs). </aside>

✅  Add free domain and SSL

Free Domain from Noip :

• Login to noip : No-IP
• Create a hostname
• Add your ec2 public IP
• and done ✅

Install free ssl in nginx using certbot

• Install certbot

sudo yum install -y certbot python3-certbot-nginx

//check version
certbot --version

• Edit your Nginx config file (likely /etc/nginx/nginx.conf or /etc/nginx/conf.d/nextjs.conf):

server {
    listen 80;
    server_name whataboutcoding.com;   # your domain name

    location / {
        proxy_pass <http://localhost:3000>;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
    }
}

• Reload nginx

sudo nginx -t
sudo systemctl reload nginx

• Run certbot to get SSL

sudo certbot --nginx -d yourdomain.ddns.net

• Certbot will ask:
  • An email (for expiry notices).
  • Agree to terms.
  • Whether to redirect all HTTP → HTTPS (choose Yes).

If successful, Certbot will:

✅ Issue certificate

✅ Configure Nginx with listen 443 ssl;

✅ Redirect port 80 → 443

• Test https:

<https://yourdomain.ddns.net>

✅  Redeploy your changes

Manual way

When you make changes locally and want them on EC2:

1. Connect to EC2

ssh -i your-key.pem ec2-user@your-ec2-public-ip

or you can directly login to ec2 instance

2. Go to your app folder

cd /home/ec2-user/your-nextjs-app

3. Pull latest code

If you use GitHub:

git pull origin main

Or if you uploaded files manually, re-upload the new version.

---

4. Install dependencies

npm install #needed if any change in package.json

5. Build your app

npm run build

6. Restart your app (with PM2)

pm2 restart nextjs-app

If you forgot the name, list processes:

pm2 list

---

✅ That’s it. Your changes are live!

This is alos an automated way of deployment using github action or github webhooks or jenkins CI CD . Lets keep it for some other day.
